Medium Voltage Transformers (Oil Transformer Rated Power up to 70 MVA)
Description
The advantages of oil transformers are high reliability in harsh environments, long lifespan, lower cost, and minimal maintenance requirements. The most common construction for oil transformers is a hermetically sealed design, meaning that the tank is completely filled with oil, and oil volume changes due to temperature fluctuations are compensated by corrugated radiators. The hermetic design prevents the effects of oxygen and moisture on the oil’s dielectric properties. As a result, the aging of transformer insulation is very slow, and the transformer’s lifespan can be very long.
- Rated Power up to 50 MVA
- Insulation Level up to 170 kV
- Rated Frequency 50 or 60 Hz
- Insulating Fluid Mineral Oil
- Hermetically Sealed or with Expansion Tank
- Standard or Reduced Losses
- Ambient Temperature -40°C to +40°C (custom orders up to -60°C)
- Outer Walls Protected with Waterproof Paint RAL 7031 or RAL 7033, with a minimum paint thickness of 120 microns, suitable for the harshest environmental conditions
- Installation for both Indoor and Outdoor Environments up to Protection Degree IP54
- High Power Cooling Options, such as ONAN, ONAF, OFAF, or OFWF
- Wide Range of Accessories
